Small Military Fast Ethernet Unmanaged Switch, 8 Port

BRAND: Techaya

Model #: MILTECH 308

Techaya Miltech 308 is a small Military-Grade, Rugged 8 port unmanaged Fast Ethernet switch, IP68 rated and smaller than a credit card

Placeholder Image
Related Accessories
  • Picture of 3M LAN Harness, Shielded, Molded

    3M LAN Harness, Shielded, Molded

    CBL308LAN

DESCRIPTION

The MILTECH 308 is a small form factor military-grade, rugged 8 port unmanaged Fast Ethernet switch. It’s small size, IP67 military grade rugged construction, and Fast Ethernet make it the ideal switching solution for command post, man packable and UAV systems. Its eight 10/100Mbps ports are plug-n-play with all Ethernet equipment and provide network connectivity for most portable Ethernet devices, including:

  • Helmet-mounted heads-up display
  • Computer
  • Navigation devices
  • Communications systems
  • IP Based Sensors

With the best combination of size, weight, power and cost (SWaP-C) in the industry, the MILTECH 308 reduces load on the soldier, providing more space for equipment that increases effectiveness and survivability. The MILTECH 308 operates on readily available 5VDC power and may easily be powered from computers and other devices with USB ports.

SPECIFICATIONS
Product ModelMILTECH 308
ManagementUnmanaged
Ports8 x 10/100
IngressIP68
DIMS (L x W x H)82.2 mm x 64.1 mm x 25.9 mm (inc connectors)
ConnectorsPower + LAN : SCE2-B-76A06-07SN-001
Weight140 g
Operating Temp-45C to +85C
MIL-STDMIL-STD-810F/G/M, MIL-STD-461E
Power5VDC, 2W (Typical)
APPLICATIONS
SOLDIER-CARRY

Ethernet in Soldier Carry applications diagram

UAV

Ethernet in UAV applications diagram
