Military Rugged 8 Ports USB Charger for USB Based Electronic Devices In Combat Vehicles

BRAND: Techaya

Part #: MILTECH 8P

The rugged MILTECH 8P mounted inside ground combat vehicles, can charge up to 8 USB based electronic devices simultaneously while providing 5Vdc, 2A per port.

Placeholder Image
DESCRIPTION

The rugged MILTECH 8P mounted inside ground combat vehicles, can charge up to 8 USB based electronic devices simultaneously while providing 5Vdc, 2A per port.

The MILTECH 8P is a Rugged USB Charger, enables to charge up to eight Smart Phones, PDA devices and other hand-held military and civil devices in APV’s, APC’s and other armored combat vehicles. Due to the increase in use of USB based electronic devices such as Smart Phones, Tablets, PDA’s in the modern battlefield, there is a constant need to charge these devices while transporting, in ground combat vehicles, to the battlefield. Thus, saving valuable battery charging capabilities to be used once the soldier dismounts from the vehicle.

SPECIFICATIONS
Product Model MILTECH 8P
Management Unmanaged
Ports Power connector + 8 USB2.0 Ports
IMMERSION IP51
DIMS 114mm x 95mm x 36.5mm
Connector Power – D38999/24WA98PA • USB Connector – UJ2-ADH-1-TH (Standard USB inlet)
Weight 300g – including dust cap
Operating Temp -45C to +85C (-49F to +185F)
MIL-STD MIL-STD-461, MIL-STD-810
Power 80W maximum at full load ; Charging Capabilities: 2A/5V per port
